40bar PET air dryer for 40 bar air compressors

FOB Reference Price:Get Latest Price
$1,800.00 - $2,000.00 / Set | 1 Set/Sets 40bar PET air dryer for 40 bar air compressors (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
SUNFILTER
Model Number:
SAD-8HTF/40
Item Name:
40bar PET air dryer for 40 bar air compressor
Air flow:
8.5m3/min
Refrigerant:
R410a
Pressure dew point:
2-10℃
Working pressure:
4Mpa or 40bar
Max. inlet temperture:
80℃
Max. ambient temperature:
40℃
Min. ambient temperature:
5℃
Cooling type:
Air-cooling
HS code:
8419399090
Type:
Air Dryer
Supply Ability
Supply Ability:
1000 Set/Sets per Month 40bar PET air dryer for 40 bar air compressors
Packaging & Delivery
Packaging Details
PLY Wooden case with 40bar PET air dryer for 40 bar air compressors
Port
Shanghai
Lead Time :
15 working days
Product Description

40bar PET air dryer for 40 bar air compressors



Designed for PET machine  from 30bar to 60bar
Sunfilter High pressure refrigerated dryers make providing continuous dry air as easy as piping a self

contained unit into yourcompressed air supply line.



Corrosion-resistant heat exchangers, an enhanced control-system and high-efficiency moisture- separation
ensure a steady long-term supply of dry air.This virtually eliminates cost due to ruined product finishes,

scrapped materials or replacement of pneumatic tools and manufacturing equipment destroyed by wet air.


These small- footprint units provide complete,affordable solutions for applications rangingfrom dry cleaning

to auto body shops, to light processing and manufacturing applications.And easy accessibility simplifies routine maintenance.


Technical Date

The technical data of the 8.5m3/min refrigerated air dryer



Item

Description

Model

SAD-8HTF/40

Air Flow capacity

8.5m³/min

Working pressure

≤4Mpa or 40 Bar

Air connections

Rc1.5

Max.inlet temperature

80℃

Max.Ambient temperature

40

Min.Ambient temperature

5

Cooling type

Air-cooling

Refrigerant

 R410a

Pressure dew point

2~10℃

Nominal Power

1.8KW

Voltage

220V/1PH/50HZ

Weight

160 KG

Dimension(L*W*H)

880*550*1020MM




Packaging & Shipping





Company Information

Shanghai Sunfilter Industry.Co.,Ltd.is a manufacturing company which is specialized in compressed air drying and purification equipment who's research,manufactory,sales and service.

The leading product is refrigerated air dryer,desiccant air dryer,compressed air filter,modular regenerative adsorption compressed air dryer,water chiller.we have the CE certification and could provide the ASME code dryer for customer.

Sunfilter has been seeking excellence all the time.the company ushers in the Denmark France Japanese ect. Nations system cold and advanced technique,equipments and the original machine pieces,meanwhile taking the advanced designing concept and exquisite Production Process,following the ISO9001 quantity management system completely.

We have been improving quality by good management,seeking development by innovation ,casting the brand in good faith,expanding the market in a win-win situtaion,our products not only throughout the country,but also export to Australia ,South America ,South America, Southeast Asia, Middle East, Europe and more than 30 Countries.



Our Services

    Whether pre-sale,in sale,after-sale,as long as the user needs the help of equipment and technical advice,our company will provide the technical information within 24 hours for free, debugging boot on spot.Having finished the debug,our engineers are responsible for the operation training for the user's staff,receiving user equipment faiure notification.

FAQ

1. Why compressed air purification?

Compressor alone is not enough.In most cases,untreated compressed air is naturally dirty,oily and wet.This condition is certainly notdesirable for industrial applications and could directly or indirectlylead to the following situations.

•     Reduction in efficiency of expensive pneumatic tools & machineries

•     Frequent costly maintenance of pneumatic tools & machineries

•     Lost of production hours with increased machines down time

•     High rejection rate of products

•     Inability to meet delivery deadlines

•     Unsatisfied customers

Hence compressed air needs to be purified or treated before they can be efficiently utilised.With theincreasing popularity of compressed air as an alternative source of utility for today’s modern production facilities,it is essential that you select the most suitable compressed air treatment systems for your plant and budget this relatively small investment into your operations to avoid daily problems with untreated compressed air which could eventually lead to expensive additional operating expensesand loss businesses.

2. Why choose Sunfilter compressed air purification?

We are professional compressed air purifing and drying system factory, founded in 2005.

There are more than 10 years of experience in OEM and ODM factory in Shanghai.

We could provide professional different scheme for different working conditions.
